DC charging gun
Model No.:
The DC charging gun is widely used in electric vehicle (EV) charging stations, public charging stations, as well as commercial and residential charging facilities. It is designed for electric vehicles that require fast charging, especially those with large battery capacities and high charging demands. DC charging guns are commonly deployed in locations such as highways, shopping centers, and parking lots to provide convenient and efficient charging services for drivers.
Benefits
Specification
| specifications | |
| rated working current | 80A/125A/200A/250A/300A |
| rated working voltage | 750V/1000V DC |
| insulation resistance | ≥100MΩ（ DC1000V） |
| dielectric strength | 3500V AC |
| leakage current | ≤10mA |
| terminal temperature rise | ＜50K |
| mechanical life | ＞10000次 |
| plug-in and pull-out force | ＜140N |
| cable fixation pull-out force | ＞250N |
| ambient temperature | -40°C-+55°C |
| flame retardant rating of the plastic shell | UL94 V-0 |
| cable flame resistance test | in accordance with the provisions of GB/T 18380.12-2008 |
| protection level | IP55 operating state |
| design basis for the product | GB/T 20234.1-2023 GB/T 20234.3-2023 |
| Electronic Lock – Pulse Type | |
| rated voltage | 12V± 10% DC |
| rated current | 2A |
| power | 24W |
| operation time | ≤200ms |
| service life | ＞60000 |
| Electronic Lock – Motor Type | |
| rated voltage | 12V± 10% DC |
| no-load current | ≤ 500mA |
| locked-rotor current | ≤1000mA |
| operation time | ≤200ms |
| service life | ＞60000 |
Features
Product Features and Advantages
Advantages:
1.Fast Charging: DC charging guns can directly charge electric vehicle batteries with higher voltage and current, significantly reducing charging time compared to AC charging. It typically charges up to 80% in 30 minutes.
2.High Efficiency: DC charging systems offer high charging efficiency, reducing energy loss and improving energy utilization.
3.Wide Applicability: Suitable for various types of electric vehicles, especially those with high demand for fast charging.
4.Time-Saving: In urgent situations or during long trips, the DC charging gun provides a faster charging solution, helping electric vehicle owners reduce waiting times for charging.
